Thank you for purchasing the E-flite

®

40-Amp Lite Pro Switch-Mode BEC

Brushless ESC. This is a lightweight, high-quality, efficient sensorless
brushless electronic speed control with an integrated switch-mode BEC.
It can operate without the need for a separate receiver battery to power
your servos and receivers, saving you weight and complication. It is
capable of up to 40 amps continuous current when using 3- to 6-series

Li-Po

battery packs. You can drive up to 7 analog or 6 digital standard-

sized servos with the BEC on any recommended input voltage. This
ESC also features safe power arming along with advanced programmable
features such as low voltage cutoff, braking, timing, throttle input range,
and more, making this truly a ‘pro series’ speed control.

Features:

• Up to 40 amps continuous current with proper air flow
and 55 amps burst current (15 seconds)
• 5V switch-mode BEC capable of 2.5 amps continuous
current on any recommended input voltage
• Drive up to 7 analog or 6 digital standard-sized servos
with the BEC on any recommended input voltage
• 3- to 6-cell Li-Po, 9- to 18-cell Ni-MH/Ni-Cd input voltage
• Programmable motor braking
• Safe power-arm mode prevents accidental starts
• Programmable low voltage cutoff with settings for 3-cell
Li-Po (9.2V), 4-cell Li-Po (12V), 5-cell Li-Po (15V), 6-cell
Li-Po (18V), or 74% of battery starting voltage
• Programmable throttle input range (1.1ms–1.9ms or 1.2ms–-1.8ms)
• Programmable soft start for helis and airplanes
• Auto motor shut down if signal is lost or there is interference
• Programmable timing—5 user-selectable ranges–use
with a large variety of brushless motors
• Optional RS232 Serial Link and software available for
PC programming
• Pre-wired connectors—E-flite EC3 on battery input and
3.5mm female gold bullets on motor output leads

Specifications
Continuous Current:

40A*

Max Burst Current:

55A (15 sec)*

Length:

66mm (2.6 in)

Width:

31mm (1.2 in)

Height:

12mm (.47 in)

Weight:

48 g (1.7 oz)

Cells:

3-6S Li-Po or 9-18 Ni-MH/Ni-Cd

Hobbywing

Battery Input Leads:

13 AWG with E-flite EC3 Connector

Motor Output Leads:

16 AWG with 3.5mm Female Gold

Bullet Connectors

* Proper cooling required

Optional RS232 Serial Link & Programming Software

Programming your ESC will be much faster and easier when you purchase
the optional RS232 Serial Link and programming software. This will
allow you to update your ESC using your laptop or PC. You must have a
Serial Port on your computer or you can purchase a separate USB to DB9
adapter (available at computer retailers).

EFLARS232 RS232 Serial Link/Programming Software

Servo Ratings with BEC Enabled:

Esc

Drives up to 7 analog or 6 digital standard-sized servos with the BEC on
any recommended input voltage. This also includes up to 7 standard
analog or 5 standard digital and 1 retract servo, perfect for 25-sized
warbird conversions.

Some servo combinations we have tested in various models include:

• 4 JR SPORT

™

MN48 (JSP20040) analog mini servos—E-flite

4 In 1 Esc 40a

Diamante 25e ARF and J-3 Cub 25e ARF

40a

• 4 JR DS3421 (JRPSDS3421) digital mini servos—E-flite Eratix 3D

25e ARF

• 7 JR MC35 (JSP20030) analog micro servos and 1 JR RT88

(JSP20080) retract servo—25-sized warbird

• 4 JR MC35 (JSP20030) analog micro servos—15-sized
sport aerobatic
• 6 JR SPORT MN48 (JSP20040) analog mini servos—E-flite Ultra

Stick 25 ARF & 15-size sport plane

• 4 Spektrum DSP75 (SPMDSP75) digital programmable super sub

Unity express 3.1 GB language install Hi, I was wondering if anybody new how to install the Engish UK language pack for Unity Express 3.1 as at the moment its a usa lady speaking and she asks for you to press the pound key instead of the hash. Oct 19, 2013  Activating IP Connectivity to Cisco Unity Express Software. Before installing the Cisco Unity Express software, activate the IP communication link between the Cisco Unified Communications Manager system and the Cisco Unity Express module. The following information is required for activating the software. To change the language from U.S. English to anything else, install a new language using the boot helper. Perform a complete installation, including a reload of all the Cisco Unity Express installation files. Refer to the Installing a Software Image Using Boot Helper section of Installing and Upgrading Cisco Unity Express Software. Oct 19, 2013  Step 1 Log in and go to the Cisco Unity Express support page at. Step 2 Click the Download Software link. Step 3 Select your Cisco Unity Express release. Step 4 Download the appropriate Cisco Unity Express software files. Step 5 Copy the core files and the language package file to the FTP. Installation Guide for Cisco Unity Connection Release 9.x Chapter 1 Installing Additional Languages on the Cisco Unity Connection 9.x Server Installing Unity Connection Language Files Note Make sure that the multilingual.cop files are installed on the exact specific CUC build that they were created for. Cisco unity express install language pack.

micro servos-E-flite Ultimate 20-300 10e ARF

Some other brands and models of servos may have significantly higher

current draw. Digital servos and binding servos of any kind typically have

higher current draw. As a general rule, micro and sub-micro servos draw

less current which may affect your servo usage as shown in the examples

above. We recommend the use of a Hangar 9 Servo and Receiver Current

Meter (HAN172), installed between the throttle lead of the ESC and

receiver, to confirm current draw of the actual servos used. Also, always

be sure to position the ESC for maximum airflow since cooling can

significantly aid in the performance of the BEC.

Before first use, please refer to “Servo Ratings with BEC Enabled” notes

for BEC usage guidelines. You must follow these guidelines for safe
operation. If you are using more than 7 analog standard servos, more than
6 digital standard servos, or servos with higher current draw than the BEC
can deliver, you will need to disable the BEC. If you wish to disable the
BEC, you must remove the red receiver wire lead and connector from the
receiver lead housing, and then insulate it properly to prevent shorting.
When operating with the BEC disabled, E-flite recommends the use of a
separate, high-power, external BEC (like the Ultimate BEC), or receiver
pack and switch using the following items to ensure trouble-free operation:

1. JR 1100mAh 4.8V Ni-MH receiver battery (JRPB4240),
or similar
2. JR Switch Harness (JRPA003), or similar

PLEASE READ THESE INSTRUCTIONS IN THEIR ENTIRETY BEFORE USE

Before you connect your ESC and begin flying, take a moment to look it
over. The input power side has a black (negative) and red (positive) wire
along with an E-flite EC3 Male Device Connector. The motor side has three
16-gauge wires (blue, red, and black) with 3.5mm female gold bullet
connectors on the ends.

The black and red wires with the EC3 Device (DEV) Connector will connect
to your power battery. The red wire connects to the red wire on your
battery pack, the black wire connects to the black wire on your battery
pack. If the wires are reversed, the ESC may be damaged.

YOU MUST

ENSURE THAT YOU CONNECT THE BATTERY POLARITY PROPERLY TO PREVENT
DAMAGE TO THE ESC. Reversing polarity will void your warranty, so always
double-check this connection. Use only a genuine E-flite EC3 Female
Battery (BATT) connector on the battery so it matches the EC3 Male
Device (DEV) connector on the speed control. The throttle lead connects
to the throttle channel on your radio receiver.

WARNING: For your safety, when checking the startup function of the ESC or
making programming changes, please remove the propeller to prevent any
potential injury. You should always treat the motor and propeller as live and
dangerous, remembering it could start at any time, and keep any body parts,
clothing and tools clear of the propeller arc. NEVER LEAVE THE BATTERY
CONNECTED WHEN NOT FLYING THE AIRCRAFT AND ALWAYS REMOVE THE
BATTERY FROM THE MODEL BEFORE CHARGING AND WHEN FINISHED FLYING.

When flying in hot weather, we recommend checking on the condition of
the ESC, battery, and motor after each flight. You may want to consider
letting the electronic components cool to near ambient temperature
between flights. We also recommend throttle management when running
near maximum levels of current draw during extreme conditions. It is not
recommended you fly an entire flight at full throttle. If this is done, it is
possible to cause permanent damage to your motor, battery, and ESC.

Using the 40-Amp Lite Pro Switch-mode BEC Brushless Controller

This controller is very simple to use, and for safety, will not arm the motor
until the throttle stick has been held in the Idle/Off position for more than
1 second. The controller will indicate the soft cutoff voltage setting every
time you plug the battery in by first emitting a low, long tone, to indicate
startup. Depending on the selected cutoff voltage (default is 74%), you
will then hear the respective number of medium length mid tones to
indicate the cell count or a musical tone for the 74% cutoff, helping you
to confirm the setting before every flight. Proper air cooling is required
during flights so the ESC should be place in an area where air flows over
the controller.

Connecting the ESC to the Motor

The three wires from your motor connect to the three female gold bullet
connectors on the ESC. The order of connection to the motor is not
important; you can plug any motor wire into any connector. When you test
the system, the motor runs backwards, you can simply unplug and switch
any two of the motor wire plugs connected to the ESC.

Mounting the ESC

Towerpro 40a Esc Manual Instructions

Choose a location that has good airflow and offers good protection. Do not

-1-

40-Amp Lite Pro Switch-Mode

BEC Brushless ESC Instructions

Advertising
Popular Brands

Towerpro 40a Esc Manual Transmission

Popular manuals
